DIN 41612 Female straight, type H15 low profile Part No. 114-40080
Illustration similar
Perpendicular
Through Hole
Power
Rugged
- Termination length 4 mm
- 15 contacts
- solder
- performance level 1
Technical Specifications
Basics
| Specification | IEC 60603-2 (DIN 41612) |
|---|---|
| Performance Level | 1 |
| No. of Contacts | 15 |
| Termination Technology | solder |
| Termination Length | 4 mm |
| Operating Temperature Range | -55°C to +125°C |
Material
| Insulator Material | PBT glass filled UL 94 V-0 |
|---|---|
| CTI value IEC 60112 | 200 |
| Contact Material | Copper alloy |
Mechanical
| Pitch | 10.16 x 6.5 mm |
|---|---|
| Mating Force | < 90 N |
| Separating Force per Pin | > 0.2 N |
| Durability | 500 mating cycles |
Electrical
| Operational Current | 15 A |
|---|---|
| Contact Resistance | <8 mΩ |
| Clearance and Creepage | cr: ≥ 8.0 mm, cl: ≥ 4.5 mm |
| Insulation Resistance | >106 MΩ |
| Test Voltage | 3100 V |
Processing
| Soldering Temperature | to 260°C |
|---|
Approval / Compliance
| UL file | E130314 |
|---|---|
| Environment | RoHS compliant |
Derating Diagram
