DIN 41612 Male 90°, type F Part No. 109-40024TH
Illustration similar
Perpendicular
Through Hole
Power
Rugged
- Termination length 3 mm
- 32 contacts
- THTR
- performance level 2
Technical Specifications
Basics
| Specification | IEC 60603-2 (DIN 41612) |
|---|---|
| Performance Level | 2 |
| No. of Contacts | 32 |
| Termination Technology | THTR |
| Termination Length | 3 mm |
| Operating Temperature Range | -55°C to +125°C |
Material
| Insulator Material | PA glass filled UL 94 V-0 |
|---|---|
| CTI value IEC 60112 | 600 |
| Contact Material | Copper alloy |
Mechanical
| Pitch | 5.08 x 3.81 mm |
|---|---|
| Mating Force | < 50 N |
| Separating Force per Pin | >0.2 N |
| Durability | 400 mating cycles |
Electrical
| Operational Current | 5.6 A |
|---|---|
| Contact Resistance | <15 mΩ |
| Clearance and Creepage | cr: ≥ 3.0 mm, cl: ≥ 1.6 mm |
| Insulation Resistance | >106 MΩ |
| Test Voltage | 1550 V |
Processing
| Soldering Temperature | 260°C per J-STD-020 |
|---|---|
| MSL | 1 |
Approval / Compliance
| Environment | RoHS compliant |
|---|
Derating Diagram
Options
Board Lock 90°
| Suitable for connectors with type B, C, D, E, F, G male connectors and R female connectors | ||||||
 |  | |||||
| Type of Insertion | Forces | PCB Thickness | Part Number | |||
| Fm | not soldered Fh | soldered Fh | 109-40024THC1 | |||
| Locked | < 30 N | > 10 N | > 20 N | ≤ 1.6 mm | ||
| Under Tension | < 30 N | > 7.5 N | > 20 N | > 1.6 mm | ||
Modifications
Available on request
- Pre-mating and late-mating contacts
- Contact arrangement
- Performance levels I + III or customer-specific
- Special contact length
Packaging
Box
19 pcs / Box
14 Box / Box
